IsoTec SE 300 Synthetic Ester Transformer Fluid

IsoTec logo

Synthetic Ester dielectric fluid sets a new benchmark for transformer performance. Proven in demanding grid and industrial applications, it offers superior thermal stability, exceptional moisture tolerance, and enhanced fire safety compared to conventional mineral oils. Its long service life reduces maintenance costs, delivering reliable, efficient power for utilities and industrial operators.

Why IsoTec SE 300?

POWER NETWORKS YOU CAN RELY ON- SAFE, SMARTER & STRONGER

IsoTec SE 300 is a high-performance synthetic ester transformer fluid designed to deliver maximum safety and reliability. It provides excellent fire protection, insulation support, and operational efficiency for modern transformers. With a fire point of 316 °C (ISO 2592) and K3 classification according to IEC 61039, IsoTec SE 300 significantly reduces fire risk compared to mineral oils. Its low pour point of −60 °C (ISO 3016) ensures reliable performance in extreme cold, while its high moisture tolerance (breakdown voltage unchanged up to 600 ppm water at 20 °C) protects insulation, slows aging, and extends transformer life. IsoTec SE 300 is readily biodegradable according to OECD 301 F (89 % biodegradation after 28 days).

High-Performance Ester Oil for Your transformer With Maximum Safety

IsoTec SE 300 is a K3 transformer fluid that replaces mineral oils. It provides excellent fire protection, strong cold resistance, and extends the service life of your equipment.

Superior Fire Safety and Risk Reduction

With a flash point of 260 °C and a fire point of 316 °C (ISO 2592) and K3 classification according to IEC 61039, IsoTec SE 300 provides a superior level of fire safety compared to conventional transformer fluids such as mineral oil. These characteristics significantly reduce the risk of transformer fires, protecting not only the equipment itself but also surrounding infrastructure and personnel.
By greatly minimizing the likelihood of a fire incident, IsoTec SE 300 helps operators comply with strict safety regulations and improve overall system reliability. In many cases, the exceptional fire safety performance of this fluid can reduce the need for additional fire protection measures, such as fire barriers or suppression systems.
This translates into lower operational risks and considerable cost savings over the lifetime of the transformer, while also simplifying the design and installation of transformer systems in sensitive or space-limited environments, such as urban substations, industrial facilities, or offshore platforms.

High flash point

Readily Biodegradable according to OECD 301 F

IsoTec SE 300 is readily biodegradable according to OECD 301 F: in this standardised test, the finished product reached 89 % biodegradation after 28 days (pass level for ready biodegradability: 60 %).

Compared with conventional mineral oils, this property can help to reduce the potential environmental effects of accidental leaks or spills, for example in aquatic environments (see U.S. EPA publication 800-R-11-002). Biodegradability does not mean that a fluid is harmless. Requirements for containment depend on the site and are determined case by case by the competent authority.

Engineered for Harsh Climates and Long-Term Durability

The extremely low pour point of −60 °C (ISO 3016) ensures that IsoTec SE 300 maintains outstanding fluidity and performance even under the harshest cold climate conditions. This makes it the ideal choice for transformer installations in arctic, alpine, or other sub-zero environments, where traditional mineral oils often become too viscous to operate effectively. As a result, transformers filled with IsoTec SE 300 continue to run smoothly and reliably, even during extreme winter conditions, ensuring uninterrupted power supply and system stability.
In addition to its cold-weather resilience, IsoTec SE 300 offers exceptional moisture tolerance, with no reduction in breakdown voltage up to 600 ppm of water at 20 °C. This property plays a critical role in protecting cellulose insulation inside the transformer. By effectively absorbing and managing moisture, IsoTec SE 300 slows down the natural aging process of insulation materials, thereby prolonging transformer life and reducing the frequency of costly maintenance or replacements.
This combination of cold-climate reliability and long-term insulation protection makes IsoTec SE 300 an ideal solution for transformers operating in demanding environments, ensuring both operational continuity and asset longevity.

Durability

Performance Highlights - Your Advantages

Exceptional Fire Safety

IsoTec SE 300 offers a high flash and fire point, providing maximum protection for your transformers under all operating conditions.

Outstanding Cold Resistance

With reliable performance down to −60 °C, it is ideal for even the most extreme climates.

Superior Oxygen Resistance

Maintains stability when exposed to air, protecting your transformer’s insulation and extending equipment life.

Multipurpose Applications

Suitable for indoor, outdoor, underground, and high-temperature installations, making it adaptable to a wide range of environments.

Readily Biodegradable

Readily biodegradable according to OECD 301 F – 89 % after 28 days.

Cost-Efficient

Reduces maintenance requirements and extends transformer life, delivering long-term cost savings.

IsoTec products are supplied to customers worldwide outside Germany. We do not offer or sell IsoTec products within Germany.
